Specification:

• Type : Frame type construction
• Capacity : 150 Tons
• Platen size : 600mm x 600mm
• Ram diameter x Stroke : 300 mm x 300 stroke
• No. of daylight : One
• Daylight Gap : 300mm
• Working pressure : 210 Bar
• Mode of heating : Electrically heated with cartridge heaters andSolid stat temp. indicator cum controller (Digital).SSR circuit.
• Sequence of operation : Electrical push button controlled withINCH and AUTO cycle, multi degassing,Curing timer etc.
• Power pack : 5HP – 1440 RPM
• Hydraulic power pack : Two stage (fast closing and slow pressingPump) with and low and high pressurerelief valve, non return directional controlvalve, with vertical flange mounted motor all mounted over an oil tank (without oil)
• Mold handling table : The press shall be provided with a operator mold table on pressfront for mould handling during loading /unloading /opening etc.

Safety : Safety grill gate ,interlocked with press movement shall be provided
