Specification:

• Tests : One loop, 2 loops and four loops cycle tests,
• Detailed graphs for each loop for 4 loop test.
• Easy hanging of FIBC’s
• Computer control.
•  Test capacity                               : 20 ton
•   Sensitivity                                   : <%1.5
• Air consumption 6 bar 50 L/min
•  Power consumption                    : 10 KVA
•  Big Bag dimensions Max            : 1200 x1200 x 3500 mm
•  Supply voltage                            : 380 Volt 3 Phase 50/60 Hz
• Graphic output                              : Excel/ Database Report

Application

Top Lift Tests and Cyclic Top Lift Tests of FIBCs with single-point and multi-point suspension according to all National and International Standards can be performed in an easy,quick and accurate manner on a high technical standard.
