Inner chamber: size 18” X 18” X 18”
Material: SS 304
Outer Chamber: Powder Quoted
Material: MS
Insulation: Puff Insulation.

Parameters:

Microprocessor based DRY/WET RH Indication and control

Temperature

Range : 10 °C to 60 °C (Degree Celsius)
Controlling : P.I.D Controlling action through SSR
Accuracy : 0.1 °C
Uniformity : ± 0.5°C

Humidity:

Range : 40% to 95% RH (Relative Humidity)
Controlling : Water Spray
Accuracy : ± 1%RH
Uniformity : ± 3%RH

Accessories:

Compressor : “Kirloskar / ANY REPUTED ” make for cooling.
Heaters : Cylindrical for heating purpose with Regulator control
Trey : 2 nos.
Door : Two Door Facility (One Is Glass Window and another one is Insulated Door)
Power : 1 phase, 230v AC, 50 HZ

Application:

Humidity Chamber can use test specimens for further physical or chemical Tests and also as environmental conditions for conducting testing of specimens.

Standard – IS 9537
