Product
| Size | 1220 X 760 X 460 mm. ( Inner Size) & As per Requirement. |
| Temp. Range. | Ambient To 20 o C. & Ambient to 100 o C. |
| Resolution. | 0.1 o C. |
| Accuracy . | +/- 0.5 % |
| Material Construction | Inner S.S. & Outer M.S. With Powder Coated Or Paint |
| Power Supply. | 415 V , 3 Phase , 50 HZ. |
1) Dimensions Of Water Bath.
- 1250mm(Length) X 600mm(Width) x 1250mm (Height) / customize
2) Material Of Construction :
- Material of Construction Inner SS-304 And outer MS Powder coated
3) Features of the water bath :
- A water drain valve made of gun-metal is to be fitted at the bottom to drain out water.
- Water Level adjustable system : with metallic ball valve .
- A Removable top cover made of : 304 quality stainless steel.
4) Temperature Range : 20 deg to 98 deg
5) Temperature Controller :
- Temperature controll : By Digital Temperature Indicator
- A Propeller type motorized stirrer is to be fitted at a suitable place inside the water bath to bring uniformity in water temperature throughout the bath within +/- 1 dec C of the temperature of the digital temperature controller at all conditions using at least three numbers of sensore fitted suitable inside the bath.
6) Display Unit :
- Electronic control LED Display.
7) Port Holes :
- Two Numbers of port holes with suitable plugging arrangment capable of accommodation.
8) Power Supply :
- 230 V AC , Single Phase , 50Hz.
Standard – ASTM D 1598, IS 4985
